What should your crawl space look like?

Most crawl space problems on Long Island come from building the wrong kind of crawl space for the lot. A house in Zone X wants a sealed, conditioned space. A house in an AE flood zone wants the same thing behind insulated flood vents. A house in a VE or Coastal A zone has to stay open underneath. Describe the crawl space you have, and this page builds the checklist for yours: what the 2025 New York codes require, what we recommend from the field, the flood-opening math, and the dehumidifiers that fit the space.

1. Describe itFlood zone, size, floor, insulation on the walls and under the floor, vents, equipment, and what you plan to do.
2. Get the planA checklist in order, each item marked Code, Recommended, or Check first, with the code section behind it.
3. Use itPrint it, send it to your contractor with a link, or have us verify it from inside the crawl space.
1Where the house sits

The flood zone decides more than anything else. Type the address and press Find my flood zone, or open the FEMA map and read the label on the colored area under the pin, for example "Zone AE (EL 9)". No color means Zone X.

2Size and shape

Inside measurements. Rough numbers are fine; the flood-opening, ventilation, and dehumidifier math uses the floor area.

3What is down there now

Open each list and check everything you have seen. More checks give a more accurate plan.

Water and moisture
Nothing checked
Equipment and utilities in the crawl space
Nothing checked
4Your plans
What is going on with the house
Nothing checked

The plan is built on this page. The only thing sent anywhere is the address, to the U.S. Census geocoder and FEMA's map service, when you press Find my flood zone.

Three ways a Long Island crawl space gets built

The flood zone decides which one applies. The planner above picks the right one for your lot; this is what each looks like and why.

Closed, conditioned crawl space20-mil walkway striphatchsealed sumpduct, sealed + insulated1234gradeNo vents. Dry air stays in; the subfloor stays warm.

1. Closed and conditioned: outside the flood zone

  1. 1Class I vapor retarder over the ground, 10 to 12 mil, lapped 6 inches, sealed, run up the wall and fastened. A 20-mil strip where people crawl, around the equipment, and under the hatch.
  2. 2Insulation on the walls, not the floor: R-15 continuous foam or the equivalent, stopped 3 inches below the sill for termite inspection, covered by the barrier the fire code requires.
  3. 3A crawl space dehumidifier rated for the area and for cold air, hung from the joists or on a wall bracket, ducted to the far end, set to 50 to 55 percent.
  4. 4Gravity drain to a sealed-lid sump or outdoors, or a condensate pump with a check valve and a safety switch. Vents sealed. Ducts sealed with mastic and still insulated.

Residential Code of New York State R408.3. This is the correction for the summer condensation, cupped floors, and musty smell that vented crawl spaces produce on the East End.

Sealed crawl space behind insulated flood vents20-mil walkway striphatchsealed sumpduct, sealed + insulated12345required flood elevation = BFE + 2 ft (+18 in tidal): equipment and new floor framing above this linegradeInsulated flood vents stay shut to air and open to water. The space can still be sealed.

2. Sealed behind insulated flood vents: Zone AE or A

  1. 1Same liner, same walkway strip. Everything below the flood elevation is a flood-resistant material: closed-cell foam, not fiberglass or open-cell.
  2. 2Closed-cell foam on the walls, R-15 continuous, stopped short of the vents so they swing free on both faces.
  3. 3Dehumidifier hung above the required flood elevation, with its outlet and any pump above it too.
  4. 4Air handler, water heater, panel, and outlets above the required flood elevation, or on a platform that is. The 2025 code sets that line at the base flood elevation plus 2 feet, plus 18 inches in tidal areas.
  5. 5Engineered flood vents rated for the area, at least two on different walls, bottoms within 12 inches of grade. The insulated type stays closed and weatherstripped against air until water rises, which is what lets the space be sealed at all.

RCNYS R306.2.2 and R306.2.2.1; FEMA Technical Bulletins 1 and 2. The vent manufacturer's ICC-ES report goes in the permit file and on the flood insurance Elevation Certificate.

Open, flood-resistant crawl space with the floor isolatedbreakaway panels with flood openings; parking, access, storage only belowR-30 closed-cell foam in contact with the subfloor, rim joist includedduct: R-8 jacket, sealed seamsground cover, not sealed to the wallsdehumidifier upstairsrequired flood elevation: nothing that water can damage below this line1234VE and Coastal A: the crawl space stays open; the floor above is the sealed, insulated boundary.

3. Open and flood-ready: Zone VE and Coastal A

  1. 1The floor above becomes the boundary: R-30 closed-cell foam against the subfloor and the rim joist. It insulates, air-seals, and survives a flood.
  2. 2Ducts that have to stay below are sealed, jacketed to R-8, and hung off the ground; better, they move up.
  3. 3A ground cover cuts soil moisture, but nothing is sealed, insulated, or stored below, and no equipment lives there.
  4. 4Humidity is controlled upstairs, with a whole-house dehumidifier inside the envelope. A dehumidifier in an open crawl space is trying to dry the outdoors.

RCNYS R306.3. New construction and substantial improvements here go on pilings or columns with breakaway walls; an existing house keeps its crawl space open, flood-vented, and empty of anything water can ruin.

Questions we get about crawl spaces

Short answers. The planner's checklist carries the code sections.

Can I seal a crawl space in a flood zone?

In Zone A or AE, yes, if the foundation keeps its flood openings. Insulated engineered flood vents are rated to equalize floodwater and stay closed to air the rest of the time, so the space can be lined, insulated with closed-cell foam, and dehumidified. In Zone VE or a Coastal A Zone, no: new work there has to sit on an open foundation, and an existing enclosure stays open and empty below the flood elevation.

What counts as a flood opening?

At least two openings on different walls, a total net area of 1 square inch per square foot of enclosed floor, each opening at least 3 inches across, with the bottom no more than 12 inches above the higher of the inside or outside grade. Standard louvered vents rarely add up once louvers and screens are counted, and vents set high in the wall do not count at all. Engineered vents carry a coverage rating in square feet from an ICC-ES evaluation report and are counted by that rating instead.

Do foundation vents dry out a crawl space here?

Not in summer. Outside air on the East End in July carries a dew point near 70 degrees; the crawl space floor, pipes, ducts, and subfloor sit well below that, so the vented air condenses on them instead of drying anything. Venting was written for a drier climate. The code's answer for a closed crawl space is a sealed ground cover plus one of three drying methods, and the one that works year-round in a seasonal house is a dehumidifier.

How big a dehumidifier do I need?

Size by the manufacturer's sealed-crawl-space coverage rating, not by pints. The pints-per-day on the box are measured at 80 degrees; a crawl space runs 55 to 65 degrees, where the same unit removes a third to half less. Choose a crawl space unit with a published low operating temperature and automatic defrost, duct it so the dry air reaches the far end, and put the sensor there. The planner lists units that fit your area and height.

Does the insulation go on the walls or under the floor?

In a closed crawl space, on the walls. Insulating the floor keeps the crawl space cold, and a cold crawl space in humid air is where condensation starts. Fiberglass batts between the joists come out. In an open crawl space in VE or Coastal A, the opposite: the walls stay bare and the floor gets closed-cell foam, which is the one insulation that tolerates flooding.

What is the difference between a crawl space and a basement for flood insurance?

A crawl space floor may sit below the outside grade only within limits: no more than 2 feet below the lowest adjacent grade, no more than 4 feet from floor to the top of the wall, with drainage, and only where the town allows it. Deeper than that it is rated as a basement, which changes the premium and what new work is permitted. Measure before you plan.

What triggers the whole-house flood rules?

A substantial improvement: work whose cost is 50 percent or more of the market value of the structure, land excluded, as determined by the town from your permit application. Cross that line and the entire house has to meet the flood code as if it were new, including floor elevation, flood openings, flood-resistant materials, and equipment above the required flood elevation. Ask the building department how they count it before plans are drawn.

Is this plan a code determination?

No. It is a checklist built from the 2025 Residential and Energy Conservation Construction Codes of New York State and FEMA's NFIP bulletins, with the section cited on each line so your contractor and building inspector can check it. The flood zone, base flood elevation, and substantial-improvement decision come from FEMA's map and your town, and every town and village on Long Island enforces its own flood damage prevention law on top of the state code, often with stricter terms. Where the local law is stricter, it governs. An assessment from inside the crawl space turns the checklist into a plan for your house.

What a crawl space assessment includes

  • Moisture readings in the joists, sills, and subfloor, and temperature and humidity logging against the outdoor air
  • Every vent counted and measured, with its height above grade, so the flood-opening math is real
  • Liner, insulation, and framing condition, with photographs
  • Equipment, ducts, drains, and electrical checked against the required flood elevation
  • Mold sampling to EMSL Analytical when the findings call for it, under a NYS mold assessor license
  • A written report your contractor can build from, with the code sections cited

Independent diagnostics only. We do not sell or install equipment, insulation, or remediation, and we take no referral fees. A 50 percent deposit schedules the visit; the report is released by Google Drive link when the balance is paid.
